ARTEVO
Inswing Casement/ Fixed / Door systems
STARR Windows and Doors proudly offers the ARTEVO™ line, a state-of-the-art window and door system designed to meet the highest performance standards in the industry. With innovative materials like RAU-FIPRO® glass-fiber reinforced PVC and RAU-FLECT™ Low-E insert technology, ARTEVO™ provides exceptional thermal insulation, structural stability, and soundproofing without the need for steel reinforcement. This advanced system allows architects, developers, and builders to deliver modern, high-efficiency solutions that elevate the aesthetic and performance of any project, all while meeting rigorous building codes and environmental standards.
REHAU ARTEVOTM window and door system offers manufacturers and specifiers powerful strength and stability for creating sweeping views with exceptional performance in commercial and residential buildings. Developed to meet Passive House certification, this undeniably versatile design provides tilt-turn, turn, hopper and fixed windows as well as balcony doors for new construction and remodeling. Choose from several color options to make it your own.
Performance summary:
AAMA/NAFS 2022: up to CW-PG100
ASTM E90 Acoustical (STC): up to STC 44 dB, OITC 37
Solar Heat Gain Coefficient (SHGC): down to 0.14
U-value: down to 0.14
Testing of our window and door systems is ongoing. Contact your REHAU representative for the latest.
Performance/ Testing
Features
RAU-FIPRO® glass-fiber reinforced PVC profile : Delivers powerful stability and torsional rigidity from floor to ceiling, supporting openings of up to 9.2 ft (2.8 m) in height
RAU-FLECTTM Low-E insert technology: Provides unmatched thermal insulation, making it easier to meet U.S. Department of Energy R-7 window program requirements and achieve Passive House cool, temperate climate certification
Compression-seal technology: Increases thermal and acoustical performance while significantly reducing closing pressure, which makes window operation easy and extends the service life
Multiple locking points surrounding the sash: Provide extra security, tighter sealing and greater comfort
Integrated reinforcement zones in frame and sash: Offer superior structural stability while making hardware fastening more secure
Up to 2-3/16 in (56 mm) glazing capability: Accommodates triple glazing, increasing energy efficiency and acoustic properties
Co-extruded glazing, compression, convection and center seals: Enhance protection against heat loss, air infiltration and water penetration while increasing manufacturing efficiencies and reducing SKUs
Seven (7) chambers in frame and sash: Provide excellent thermal, water and sound insulation
93-5/32 in (80 mm) frame depth: Offers installation flexibility while delivering superior structural and thermal performance
4-19/32 in (117 mm) combined frame and sash height: Provides more expansive daylight opening
Frame material: top layer | RAU-PVC cadmium- and lead-free formulation |
Frame material core | RAU-FIPRO glass fiber-reinforced PVC |
Sealing system | Center seal |
Construction depth | 3-5/32 in (80 mm) |
Number of chambers | Frame profiles: 7, sashes: 5 to 7 |
Seal overlap | Outside: 3.5 mm, inside: 8 mm |
Seal gap | Outside: 5mm, inside: 4 mm |
Hinge axis | 12 mm |
Maximum Ig. thickness sash Z/T | 2-3/16 in (56 mm) |
Profile sightlines frame sash | 117 mm to 138 mm |
Heat transfer coefficient Uf | Up to 0.97 W/(m2K) |
Heat transfer coefficient Uf ARTEVO with Low-E insert | Up to 0.81 W/(m2K) |
Heat transfer coefficient Uw ARTEVO with Low-E insert | 0.80 W/(m2K) from Passive House Institute |
Structural | Up to CW-PG100 |
Watertightness | Up to DP 100 |
Acoustic insulation | Up to 44 db, OITC 37 |
Solar Heat Gain Coefficient | Down to 0.14 |
Thermal insulation | Down to 0.14 |
